DNSViz: A DNS visualization tool

q.licensedns.net

DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
  10. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (5)
  • q.licensedns.net/A
  • q.licensedns.net/AAAA
  • q.licensedns.net/NS
  • q.licensedns.net/SOA
  • q.licensedns.net/TXT

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (14)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 26470)
  • ./DNSKEY (alg 8, id 38696)
  • ./DNSKEY (alg 8, id 53148)
  • licensedns.net/DNSKEY (alg 13, id 2371)
  • licensedns.net/DNSKEY (alg 13, id 34505)
  • licensedns.net/DS (alg 13, id 2371)
  • net/DNSKEY (alg 13, id 10024)
  • net/DNSKEY (alg 13, id 37331)
  • net/DNSKEY (alg 13, id 45412)
  • net/DS (alg 13, id 37331)
  • q.licensedns.net/DNSKEY (alg 13, id 56743)
  • q.licensedns.net/DNSKEY (alg 13, id 7862)
  • q.licensedns.net/DS (alg 13, id 7862)

Delegation statusDelegation status

Secure (3)
  • . to net
  • licensedns.net to q.licensedns.net
  • net to licensedns.net

NoticesNotices

Errors (1)
  • net zone: The server(s) responded over TCP with a malformed response or with an invalid RCODE. See RFC 1035, Sec. 4.1.1. (192.54.112.30)
Warnings (3)
  • net/DNSKEY (alg 13, id 10024): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (192.54.112.30, UDP_-_EDNS0_4096_D_KN)
  • net/DNSKEY (alg 13, id 37331): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (192.54.112.30, UDP_-_EDNS0_4096_D_KN)
  • net/DNSKEY (alg 13, id 45412): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (192.54.112.30, UDP_-_EDNS0_4096_D_KN)

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
