DNSViz: A DNS visualization tool

org.ls

DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
  10. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Insecure (3)
  • ls/SOA
  • org.ls/NS
  • org.ls/SOA
Secure (1)
  • ./SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (3)
  • ./DNSKEY (alg 8, id 18733)
  • ./DNSKEY (alg 8, id 20326)
  • NSEC proving non-existence of ls/DS

Delegation statusDelegation status

Insecure (2)
  • . to ls
  • ls to org.ls

NoticesNotices

Errors (11)
  • ls zone: The server(s) were not responsive to queries over UDP. See RFC 1035, Sec. 4.2. (196.11.175.1)
  • ls/DNSKEY: No response was received from the server over UDP (tried 4 times). See RFC 1035, Sec. 4.2. (196.216.168.70, UDP_-_EDNS0_512_D_KN)
  • org.ls zone: The server(s) were not responsive to queries over UDP. See RFC 1035, Sec. 4.2. (196.11.175.1)
  • org.ls/DNSKEY: No response was received from the server over UDP (tried 12 times). See RFC 1035, Sec. 4.2. (196.216.168.70, UDP_-_NOEDNS_)
  • org.ls/DNSKEY: No response was received from the server over UDP (tried 4 times). See RFC 1035, Sec. 4.2. (196.216.168.70, UDP_-_EDNS0_512_D_KN)
  • org.ls/DS: No response was received from the server over UDP (tried 12 times). See RFC 1035, Sec. 4.2. (196.216.168.70, UDP_-_NOEDNS_)
  • org.ls/NS: No response was received from the server over UDP (tried 12 times). See RFC 1035, Sec. 4.2. (196.11.175.1, UDP_-_NOEDNS_)
  • org.ls/SOA: No response was received from the server over UDP (tried 12 times). See RFC 1035, Sec. 4.2. (196.216.168.70, UDP_-_NOEDNS__0x20)
  • org.ls/DS has errors; select the "Denial of existence" DNSSEC option to see them.
  • org.ls/DNSKEY has errors; select the "Denial of existence" DNSSEC option to see them.
  • org.ls/A has errors; select the "Denial of existence" DNSSEC option to see them.
Warnings (3)
  • org.ls/SOA: No response was received from the server over UDP (tried 10 times) until the DO EDNS flag was cleared (however, this server appeared to respond legitimately to other queries with the DO EDNS flag set). See RFC 6891, Sec. 6.1.4. (196.216.168.70, UDP_-_EDNS0_4096_D_KN)
  • org.ls/AAAA has warnings; select the "Denial of existence" DNSSEC option to see them.
  • m8dc2gyrwn.org.ls/A has warnings; select the "Denial of existence" DNSSEC option to see them.

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
