DNSViz: A DNS visualization tool

bitcoincore.org

DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
  10. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (7)
  • bitcoincore.org/A
  • bitcoincore.org/CDNSKEY
  • bitcoincore.org/CDS
  • bitcoincore.org/MX
  • bitcoincore.org/NS
  • bitcoincore.org/SOA
  • bitcoincore.org/TXT

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (10)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 38696)
  • ./DNSKEY (alg 8, id 61809)
  • bitcoincore.org/DNSKEY (alg 13, id 54958)
  • bitcoincore.org/DNSKEY (alg 13, id 56028)
  • bitcoincore.org/DS (alg 13, id 56028)
  • org/DNSKEY (alg 8, id 26974)
  • org/DNSKEY (alg 8, id 37593)
  • org/DNSKEY (alg 8, id 57769)
  • org/DS (alg 8, id 26974)

Delegation statusDelegation status

Secure (2)
  • . to org
  • org to bitcoincore.org

NoticesNotices

Errors (16)
  • bitcoincore.org zone: The server(s) responded over TCP with a malformed response or with an invalid RCODE. See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2)
  • bitcoincore.org zone: The server(s) responded over UDP with a malformed response or with an invalid RCODE. See RFC 1035, Sec. 4.1.1. (216.66.1.2)
  • bitcoincore.org/A: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN)
  • bitcoincore.org/CDNSKEY: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN)
  • bitcoincore.org/CDS: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN)
  • bitcoincore.org/DNSKEY: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN, UDP_-_EDNS0_512_D_KN)
  • bitcoincore.org/MX: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN, UDP_-_EDNS0_512_D_KN)
  • bitcoincore.org/NS: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, UDP_-_EDNS0_4096_D_KN)
  • bitcoincore.org/SOA: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, TCP_-_EDNS0_4096_D_N)
  • bitcoincore.org/SOA: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, 2001:470:400::2, UDP_-_EDNS0_4096_D_KN, UDP_-_EDNS0_4096_D_KN_0x20)
  • bitcoincore.org/TXT: The response had an invalid RCODE (REFUSED). See RFC 1035, Sec. 4.1.1. (216.66.1.2, UDP_-_EDNS0_4096_D_KN)
  • bitcoincore.org/CNAME has errors; select the "Denial of existence" DNSSEC option to see them.
  • bitcoincore.org/DNSKEY has errors; select the "Denial of existence" DNSSEC option to see them.
  • bitcoincore.org/NSEC3PARAM has errors; select the "Denial of existence" DNSSEC option to see them.
  • sdu9e.od9hw.bitcoincore.org/A has errors; select the "Denial of existence" DNSSEC option to see them.
  • bitcoincore.org/AAAA has errors; select the "Denial of existence" DNSSEC option to see them.
Warnings (2)
  • org to bitcoincore.org: The following NS name(s) were found in the authoritative NS RRset, but not in the delegation NS RRset (i.e., in the org zone): ns-a.as397444.net See RFC 1034, Sec. 4.2.2.
  • org to bitcoincore.org: The following NS name(s) were found in the delegation NS RRset (i.e., in the org zone), but not in the authoritative NS RRset: ns-a.as397444.org See RFC 1034, Sec. 4.2.2.

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
