DNSViz: A DNS visualization tool

berkeley.edu

Updated: 2022-05-03 13:16:41 UTC (59 days ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (5)
  • berkeley.edu/A
  • berkeley.edu/MX
  • berkeley.edu/NS
  • berkeley.edu/SOA
  • berkeley.edu/TXT

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (11)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 47671)
  • berkeley.edu/DNSKEY (alg 10, id 20949)
  • berkeley.edu/DNSKEY (alg 10, id 21941)
  • berkeley.edu/DNSKEY (alg 10, id 26102)
  • berkeley.edu/DNSKEY (alg 10, id 57146)
  • berkeley.edu/DS (alg 10, id 16914)
  • berkeley.edu/DS (alg 10, id 20949)
  • edu/DNSKEY (alg 8, id 28065)
  • edu/DNSKEY (alg 8, id 43304)
  • edu/DS (alg 8, id 28065)
Non_existent (1)
  • berkeley.edu/DNSKEY (alg 10, id 16914)

Delegation statusDelegation status

Secure (2)
  • . to edu
  • edu to berkeley.edu

NoticesNotices

Errors (3)
  • berkeley.edu zone: The server(s) were not responsive to queries over UDP. (2607:f140:a000:d::abc)
  • berkeley.edu/A: No response was received from the server over UDP (tried 12 times). (2607:f140:a000:d::abc, UDP_-_NOEDNS_)
  • berkeley.edu/NS: No response was received from the server over UDP (tried 12 times). (2607:f140:a000:d::abc, UDP_-_NOEDNS_)
Warnings (15)
  • RRSIG berkeley.edu/A alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 20949: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 20949: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 20949: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 20949: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/DNSKEY alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/MX alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/NS alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/SOA alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • RRSIG berkeley.edu/TXT alg 10, id 21941: DNSSEC specification recommends not signing with DNSSEC algorithm 10 (RSASHA512).
  • edu to berkeley.edu: Authoritative AAAA records exist for adns1.berkeley.edu, but there are no corresponding AAAA glue records.
  • edu to berkeley.edu: Authoritative AAAA records exist for adns2.berkeley.edu, but there are no corresponding AAAA glue records.

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
