DNSViz: A DNS visualization tool

be

DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
  10. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (3)
  • be/NS
  • be/NSEC3PARAM
  • be/SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (8)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 38696)
  • ./DNSKEY (alg 8, id 53148)
  • be/DNSKEY (alg 8, id 20124)
  • be/DNSKEY (alg 8, id 29088)
  • be/DNSKEY (alg 8, id 52756)
  • be/DNSKEY (alg 8, id 62188)
  • be/DS (alg 8, id 52756)

Delegation statusDelegation status

Secure (1)
  • . to be

NoticesNotices

Errors (1)
  • ./DNSKEY: No response was received from the server over UDP (tried 3 times). See RFC 1035, Sec. 4.2. (170.247.170.2, 192.112.36.4, 193.0.14.129, 198.97.190.53, 199.7.83.42, 2001:500:12::d0d, 2001:500:9f::42, 2801:1b8:10::b, UDP_-_EDNS0_512_D_KN)

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
