DNSViz: A DNS visualization tool

mil

Updated: 2024-04-20 05:56:04 UTC (2 hours, 1 minute ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (3)
  • mil/NS
  • mil/NSEC3PARAM
  • mil/SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (6)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 5613)
  • mil/DNSKEY (alg 8, id 16801)
  • mil/DNSKEY (alg 8, id 25501)
  • mil/DNSKEY (alg 8, id 45154)
  • mil/DS (alg 8, id 16801)

Delegation statusDelegation status

Secure (1)
  • . to mil

NoticesNotices

Errors (2)
  • mil zone: The server(s) were not responsive to queries over UDP. (2608:120:c:162::234, 2608:140:c:157::234, 2608:4163:1:143::234, 2608:c144:1:155::234, 2608:c184:1:180::234)
  • mil/NS: No response was received from the server over UDP (tried 12 times). (2608:120:c:162::234, 2608:140:c:157::234, 2608:4163:1:143::234, 2608:c144:1:155::234, 2608:c184:1:180::234, UDP_-_NOEDNS_)

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
