DNSViz: A DNS visualization tool

army.mil

Updated: 2023-09-28 15:39:55 UTC (4 days ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (7)
  • army.mil/A
  • army.mil/MX
  • army.mil/NS
  • army.mil/NSEC3PARAM
  • army.mil/SOA
  • army.mil/SOA
  • army.mil/TXT

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (15)
  • ./DNSKEY (alg 8, id 11019)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 46780)
  • army.mil/DNSKEY (alg 8, id 13536)
  • army.mil/DNSKEY (alg 8, id 21310)
  • army.mil/DNSKEY (alg 8, id 30231)
  • army.mil/DNSKEY (alg 8, id 31899)
  • army.mil/DNSKEY (alg 8, id 559)
  • army.mil/DS (alg 8, id 559)
  • army.mil/DS (alg 8, id 559)
  • mil/DNSKEY (alg 8, id 14098)
  • mil/DNSKEY (alg 8, id 16801)
  • mil/DNSKEY (alg 8, id 44065)
  • mil/DNSKEY (alg 8, id 62470)
  • mil/DS (alg 8, id 16801)

Delegation statusDelegation status

Secure (2)
  • . to mil
  • mil to army.mil

NoticesNotices

Warnings (8)
  • army.mil/DS (alg 8, id 559): DNSSEC specification prohibits signing with DS records that use digest algorithm 1 (SHA-1).
  • army.mil/DS (alg 8, id 559): DNSSEC specification prohibits signing with DS records that use digest algorithm 1 (SHA-1).
  • army.mil/DS (alg 8, id 559): DS records with digest type 1 (SHA-1) are ignored when DS records with digest type 2 (SHA-256) exist in the same RRset.
  • army.mil/DS (alg 8, id 559): DS records with digest type 1 (SHA-1) are ignored when DS records with digest type 2 (SHA-256) exist in the same RRset.
  • mil/DNSKEY (alg 8, id 14098): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. (2608:120:c:162::234, UDP_-_EDNS0_4096_D_KN)
  • mil/DNSKEY (alg 8, id 16801): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. (2608:120:c:162::234, UDP_-_EDNS0_4096_D_KN)
  • mil/DNSKEY (alg 8, id 44065): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. (2608:120:c:162::234, UDP_-_EDNS0_4096_D_KN)
  • mil/DNSKEY (alg 8, id 62470): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. (2608:120:c:162::234, UDP_-_EDNS0_4096_D_KN)

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
