DNSViz: A DNS visualization tool

apps.mil

Updated: 2023-10-27 18:11:18 UTC (241 days ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Insecure (4)
  • apps.mil/NS
  • apps.mil/NSEC3PARAM
  • apps.mil/SOA
  • apps.mil/TXT
Secure (1)
  • mil/SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Insecure (3)
  • apps.mil/DNSKEY (alg 8, id 32206)
  • apps.mil/DNSKEY (alg 8, id 33978)
  • apps.mil/DNSKEY (alg 8, id 36970)
Secure (7)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 46780)
  • NSEC3 proving non-existence of apps.mil/DS
  • mil/DNSKEY (alg 8, id 16801)
  • mil/DNSKEY (alg 8, id 29343)
  • mil/DNSKEY (alg 8, id 44065)
  • mil/DS (alg 8, id 16801)

Delegation statusDelegation status

Insecure (1)
  • mil to apps.mil
Secure (1)
  • . to mil

NoticesNotices

Errors (10)
  • NSEC3 proving non-existence of apps.mil/DS: An iterations count of 0 must be used in NSEC3 records to alleviate computational burdens. See RFC 9276, Sec. 3.1.
  • NSEC3 proving non-existence of apps.mil/DS: An iterations count of 0 must be used in NSEC3 records to alleviate computational burdens. See RFC 9276, Sec. 3.1.
  • apps.mil zone: The server(s) were not responsive to queries over UDP. See RFC 1035, Sec. 4.2. (2608:102:0:182d:1001:9012:c00:21, 2608:125:0:1811:1001:9012:f00:21, 2608:145:0:180b:1001:9012:d00:21)
  • apps.mil/NS: No response was received from the server over UDP (tried 12 times). See RFC 1035, Sec. 4.2. (2608:102:0:182d:1001:9012:c00:21, 2608:125:0:1811:1001:9012:f00:21, 2608:145:0:180b:1001:9012:d00:21, UDP_-_EDNS0_4096_D_N, UDP_-_NOEDNS_)
  • apps.mil/DS has errors; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/AAAA has errors; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/A has errors; select the "Denial of existence" DNSSEC option to see them.
  • sjg0hxdoz9.apps.mil/A has errors; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/MX has errors; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/CNAME has errors; select the "Denial of existence" DNSSEC option to see them.
Warnings (14)
  • NSEC3 proving non-existence of apps.mil/DS: The salt value for an NSEC3 record should be empty. See RFC 9276, Sec. 3.1.
  • NSEC3 proving non-existence of apps.mil/DS: The salt value for an NSEC3 record should be empty. See RFC 9276, Sec. 3.1.
  • mil to apps.mil: AAAA glue records exist for ns.cybercom.mil, but there are no corresponding authoritative AAAA records. See RFC 1034, Sec. 4.2.2.
  • mil to apps.mil: AAAA glue records exist for ns.jtfgno.mil, but there are no corresponding authoritative AAAA records. See RFC 1034, Sec. 4.2.2.
  • mil to apps.mil: AAAA glue records exist for ns1.csd.disa.mil, but there are no corresponding authoritative AAAA records. See RFC 1034, Sec. 4.2.2.
  • mil/DNSKEY (alg 8, id 16801): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (2608:4122:2:154::234, UDP_-_EDNS0_4096_D_KN)
  • mil/DNSKEY (alg 8, id 29343): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (2608:4122:2:154::234, UDP_-_EDNS0_4096_D_KN)
  • mil/DNSKEY (alg 8, id 44065): No response was received until the UDP payload size was decreased, indicating that the server might be attempting to send a payload that exceeds the path maximum transmission unit (PMTU) size. See RFC 6891, Sec. 6.2.6. (2608:4122:2:154::234, UDP_-_EDNS0_4096_D_KN)
  • apps.mil/DS has warnings; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/AAAA has warnings; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/A has warnings; select the "Denial of existence" DNSSEC option to see them.
  • sjg0hxdoz9.apps.mil/A has warnings; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/MX has warnings; select the "Denial of existence" DNSSEC option to see them.
  • apps.mil/CNAME has warnings; select the "Denial of existence" DNSSEC option to see them.

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
