DNSViz: A DNS visualization tool

ac.mw

Updated: 2025-01-02 12:50:28 UTC (11 hours, 26 minutes ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
  8. |?|
  9. |?|
  10. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Insecure (5)
  • ac.mw/NS
  • ac.mw/SOA
  • ac.mw/SOA
  • mw/SOA
  • mw/SOA
Secure (1)
  • ./SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (4)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 26470)
  • ./DNSKEY (alg 8, id 61050)
  • NSEC proving non-existence of mw/DS

Delegation statusDelegation status

Insecure (2)
  • . to mw
  • mw to ac.mw

NoticesNotices

Errors (3)
  • ac.mw/DNSKEY: No response was received from the server over UDP (tried 4 times). See RFC 1035, Sec. 4.2. (147.28.0.39, UDP_-_EDNS0_512_D_KN)
  • mw/DNSKEY: No response was received from the server over UDP (tried 4 times). See RFC 1035, Sec. 4.2. (2001:418:1::39, UDP_-_EDNS0_512_D_KN)
  • ac.mw/DNSKEY has errors; select the "Denial of existence" DNSSEC option to see them.
Warnings (9)
  • . to mw: The glue address(es) for domwe.sdn.mw (41.87.5.162, 196.45.190.9) differed from its authoritative address(es) (41.87.2.154, 41.87.5.162, 196.45.190.9). See RFC 1034, Sec. 4.2.2.
  • ac.mw/NS: No response was received from the server over UDP (tried 6 times) until the COOKIE EDNS option was removed (however, this server appeared to respond legitimately to other queries with the COOKIE EDNS option present). See RFC 6891, Sec. 6.1.2. (147.28.0.39, UDP_-_EDNS0_4096_D_KN)
  • ac.mw/SOA: No response was received from the server over UDP (tried 6 times) until the COOKIE EDNS option was removed (however, this server appeared to respond legitimately to other queries with the COOKIE EDNS option present). See RFC 6891, Sec. 6.1.2. (147.28.0.39, 2001:418:1::39, UDP_-_EDNS0_4096_D_KN)
  • mw to ac.mw: No response was received from the server over UDP (tried 6 times) until the COOKIE EDNS option was removed (however, this server appeared to respond legitimately to other queries with the COOKIE EDNS option present). See RFC 6891, Sec. 6.1.2. (2001:418:1::39, UDP_-_EDNS0_4096_D_KN)
  • ac.mw/A has warnings; select the "Denial of existence" DNSSEC option to see them.
  • ac.mw/TXT has warnings; select the "Denial of existence" DNSSEC option to see them.
  • ac.mw/DS has warnings; select the "Denial of existence" DNSSEC option to see them.
  • ac.mw/DNSKEY has warnings; select the "Denial of existence" DNSSEC option to see them.
  • ac.mw/AAAA has warnings; select the "Denial of existence" DNSSEC option to see them.

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
