DNSViz: A DNS visualization tool

edu.sa

Updated: 2024-05-06 06:20:59 UTC (13 days ago) Update now
« Previous analysis | Next analysis »
DNSSEC options (hide)
  1. |?|
  2. |?|
  3. |?|
  4. |?|
  5. |?|
  6. |?|
  7. |?|
Notices
DNSSEC Authentication Chain

RRset statusRRset status

Secure (3)
  • edu.sa/NS
  • edu.sa/NSEC3PARAM
  • edu.sa/SOA

DNSKEY/DS/NSEC statusDNSKEY/DS/NSEC status

Secure (8)
  • ./DNSKEY (alg 8, id 20326)
  • ./DNSKEY (alg 8, id 5613)
  • edu.sa/DNSKEY (alg 8, id 23553)
  • edu.sa/DNSKEY (alg 8, id 790)
  • edu.sa/DS (alg 8, id 790)
  • sa/DNSKEY (alg 8, id 26499)
  • sa/DNSKEY (alg 8, id 65380)
  • sa/DS (alg 8, id 65380)

Delegation statusDelegation status

Secure (2)
  • . to sa
  • sa to edu.sa

NoticesNotices

Errors (2)
  • edu.sa zone: The server(s) were not responsive to queries over TCP. (86.51.28.37, 86.51.77.213, 213.236.36.92, 2001:67c:18c8:c0::c1, 2a02:d70:64:68::2)
  • edu.sa/SOA: No response was received from the server over TCP (tried 3 times). (86.51.28.37, 86.51.77.213, 213.236.36.92, 2001:67c:18c8:c0::c1, 2a02:d70:64:68::2, TCP_-_EDNS0_4096_D_N)

DNSKEY legend

Full legend
SEP bit setSEP bit set
Revoke bit setRevoke bit set
Trust anchorTrust anchor
Download: png | svg
Warning JavaScript is required to make the graph below interactive.
DNSSEC authentication graph
